The H255E-U module is a highly integrated single-chip 802.11a/b/g/n 1T1R WLAN

  The H255E-U module provides USB interface for Wi-Fi

  The module provides simple legacy and 20MHz/40MHz 2.4G+5G co-existence mechanisms to ensure backward and network compatibility.

Application Scenario

  Operate at ISM frequency bands (2.4GHz)

  Support 5G frequency band

  USB2.0 for Wi-Fi

  IEEE standards support: IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

  Enterprise level security which can apply WPA/WPA2 certification for Wi-Fi.

  Wi-Fi 1 T 1R allow data rates supporting up to 150 Mbps PHY rates

Application Scenario

Application Scenario

Application Scenario

Application Scenario
