The 6235Z-RRB module is a highly integrated low power 802.11 b/g/n Wireless LAN (WLAN) and Bluetooth camera module.

  The 6235Z-RRB module provides useful high speed connectivity interfaces, such as USB 2.0 host, USB 2.0 device, SD host and Ethernet interfaces

  The 6235Z-RRB module combines ARM v8M MCUs (500MHz and 2.23 DMIPS/MHz), WLAN MAC, a1T1R capable WLAN baseband, Bluetooth MAC, RF, audio codec, ISP and H264/H265 encoder in a single chip.

Application Scenario

  802.11e QoS Enhancement (WMM)

  Wi-Fi WEP, WPA, WPA2, WPA3, WPS. Open, shared key, and pair-wise key authentication services

  Supports low power Tx/Rx for short-range application

  Maximum 4 UART interface, baud rate up to 4MHz and all of them can be configurable as log UART

Application Scenario

Application Scenario

Application Scenario

Application Scenario
