The 3101N-I Module is a integrated 2.4GHz SoC BLE & SLE module with integrated BLE5.3/SLE1.0 and RF circuit

  The 3101N-I Module supports f 1M / 2M / 4M 3 bandwidth, the maximum support of 12 Mbit / s rate

  The 3101N-I Module supports LiteOS, and provide an open, easy-to-use development and debugging operation

  The 3101N-I Module integrated high-performance 32bit microprocessor (MCU), hardware security engine, and rich peripherals Port, the peripheral interfaces include SPI, UART, I2C, PWM, GPIO, USB2.0, NFC Tag, PDM, I2S / PCM

Application Scenario

  Bluetooth BLE and SLE dual-mode coexistence are supported

  Built-in RISC-V high-performance 32bit CPU, the maximum main frequency support of 64 MHz

  Support for floating point, support for SWD

  Support SRAM 160KB

  Built-in at 512KB Flash

  Support for encryption: AES (Advanced Encryption Standard), SM4, and TRNG (True Random Number Generator）

Application Scenario

Application Scenario

Application Scenario

Application Scenario
