QOGRISYS BES2600 5gwifi module 150mbps 802.11a/n AIoT module usb wifi modules

V200Z-R

QOGRISYS BES2600 5gwifi module 150mbps 802.11a/n AIoT module usb wifi modules

Protocol：802.11a/n
Size：20*28mm
Rate：150Mbps
Frequency Band：2.4GHz
Interface：USB2.0, UART, I2C, I2S, SDIO device, MIPI, PWM, GPIO

The V200Z-R module is is based on BES2600 solution which features a Cortex-M33 Star dual-core MCU subsystem and a Cortex-A7 dual-core AP subsystem

The V200Z-R module supports low power Wi-Fi 4 (1x1 802.11a/b/g/n dual-band) and Bluetooth 5.2 dual-mode (support BT/BLE, LE Audio).

Both MCU and AP subsystem are able to run RTOS and user applications

The V200Z-R module provides a high-performance on-board printing antenna to reduce the complexity of hardware design

Application Scenario

CMOS single-chip fully-integrated PMU, CODEC, RF, BB, MCU and AP subsystem

300MHz ARM Cortex-M33 Star dual-core MCU subsystem

1GHz ARM Cortex-A7 dual-core AP subsystem with NEON

Shared 2MB SRAM, on-chip PSRAM and on-chip NOR flash

Support TrustZone and secure boot

Application Scenario
