3121N-ISC
QOGRISYS 3121N-ISC IoT Module Uart Interface Power Line Communication PLC Wifi Module
Protocol：IEEE P1901.1
Size：14.2*20mm
Rate:0.507Mbps
Frequency Band：0.5-3.7MHz and 2.5-5.7MHz（software configurable）
Interface：I2C, UART, PWM, GPIO, ADC
The 3121N-ISC module is a highly integrated, small size and low consumption Power Line Communication (PLC) module for IoT applications
The 3121N-ISC module is integrated with multi-mode power line communication modem, a
built-in line driver and an ARM Cortex-M3 MCU
The 3121N-ISC is compliant with IEEE P1901.1 standard and supports OFDM/FSK modulation
Application Scenario
Built-in SRAM 256KB
Support IEEE 1901.1
High efficient Cortex-M3 processor, operating at up to 200MHz frequency
Support frequency band 0.5-3.7MHz and 2.5-5.7MHz, software configurable
Application Scenario
Application Scenario
Application Scenario
Application Scenario
