The 6162C-IC module is a low-cost, low-power Bluetooth 5.0 module with Mesh functionality

   The 6162C-IC module is a highly integrated ARM Cortex-M4F 32-bit CPU, 160kByte RAM and 512kByte flash MCU, and Bluetooth 5.0 LE transceiver Mesh network solution

  The 6162C-IC module meets the Bluetooth 5.0 LE standard and provides UART interfaces for Bluetooth

  6162C-IC Modules of moderate size, suitable for intelligent LED and other applications

Application Scenario

  Supports Bluetooth 5 core specification

  Supports 2M LE ，LE Long Range，LE Data Length Extensions（257 byte）

  Supports OTA (Over-the-Air)programming mechanism for firmware upgrade

  UART x 2，one for data transceiver，the other for firmware upgrade

  Embedded 4Mbits Flash

  Supports 5 GPIOs

  Embedded Switching Regulator(SWR) for low current consumption
