The 6188S-UF module is a highly integrated, high performance 802.11 b/g/n WLAN SoC chip with USB interface (USB 2.0 compliant)

  The 6188S-UF module provides simple legacy and 20MHz/ 40MHz co-existence mechanisms to ensure backward and network compatibility.

  The 6188S-UF module integrates whole Wi-Fi function blocks into a chip, such as USB/PCM, MAC, BB, AFE, RFE, PA, EEPROM and LDO/SWR

  The 6188S-UF module provides USB interface for Wi-Fi

Application Scenario

  Support802.11b/g/n 1T1R WLAN

  Complies with USB2.0 for WLAN

  Wi-Fi 1 transmitter and 1 receiver allow data rates supporting up to 150 Mbps downstream and 150 Mbps upstream PHY rates

  Enterprise level security which can apply WPA/WPA2 certification for Wi-Fi.

  IEEE standards support: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11d,IEEE 802.11e, IEEE 802.11h, IEEE 802.11i
