K265B-UU
QOGRISYS K265B-UU wifi bt wifi module 802.11 ax 2x2 wi fi 1200Mbps usb wifi module 802.11 ax 2x2 wi fi
Protocol：802.11ax
Size：13*15mm
Rate：1200Mbps
Frequency Band：2.4/5GHz
Interface：USB
The K265B-UU Module is a Wi-Fi/Bluetooth combo chip supporting 2T2R 802.11ax and Bluetooth 5.4
The Wi-Fi system integrates PMU, MAC, PHY and Radio
The K265B-UU Module supports Wireless LAN (WLAN) USB interface controller
The max PHY data rate can reach up to 1201Mbps when operating at 80MHz bandwidth
The K265B-UU Module supports USB 2.0 host interface.
Application Scenario
IEEE 802.11a/b/g/n/ac/ax compatible WLAN
Supports 20/40/80MHz bandwidth and modulation up to 1024-QAM
Integrated PA/LNA/TR switch and single-ended RF port for both 2.4GHz and 5GHz
Wi-Fi and Bluetooth co-existence
Security features: − Supports WEP-40/WEP-104, AES/TKIP/CCMP/GCMP
− Supports WPA/WPA2/WPA3 personal, WPA2/WPA3 enterprise
− Supports WPS2.0
− Supports WAPI
Application Scenario
Application Scenario
Application Scenario
Application Scenario
