QOGRISYS 3243A-S 802.11b/g/n/ax WIFI+BLE5.2+SLE1.0 Combo SDIO Wifi Modules

3243A-S

QOGRISYS 3243A-S 802.11b/g/n/ax WIFI+BLE5.2+SLE1.0 Combo USB Wifi Modules

Protocol：802.11ax
Size：12*12mm
Rate：150Mbps
Frequency Band：2.4GHz
Interface：SDIO

Download

The 3243A-S Module is a highly integrated 2.4GHz Wi-Fi, BLE and SLE Combo chip

The 3243A-S Module supports 802.11n 20MHz / 40 MHz width, 802.11ax 20MHz width

Its maximum 150Mbps physical layer rate and further coverage distance

The 3243A-S Module integrated IEEE 802.11b/g/n/ax baseband and RF circuit, including power amplifier PA, low noise amplifier LNA, RF balun, antenna switch and power management module

Application Scenario

802.11b/g/n/ax 1T1R WLAN and BLE 5.2/ SLE1.0 combo chip

Complete 802.11n solution for both 2.4GHz(ch1-ch14) band

Supports 802.11n 20MHz/40MHz bandwidth and 802.11ax 20MHz bandwidth

Support maximum speed: 150Mbps@HT40 MCS7, 114.7Mbps@HE20 MCS9

Application Scenario

3243A-S

3243A-S
