The F89FTSM13-W7 module is a highly integrated single-chip 802.11b/g/n 1T1R WLAN

  The F89FTSM13-W7 module is a highly integrated single-chip 1*1 SISO Wireless LAN (WLAN) SDIO network interface

   The F89FTSM13-W7 module provide a raw data transfer rate up to 150 Mbps

Application Scenario

  Enterprise level security which can apply WPA/WPA2 certification for WiFi

  Operate at ISM frequency bands (2.4GHz)

  IEEE standards support: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

  WiFi 1 transmitter and 1 receiver allow data rates supporting up to 150 Mbps downstream and 150Mbps upstream PHY rates
