QOGRISYS SV6256P 5gwifi module 150mbps 802.11a/n sdio wifi modules

H256A-S

QOGRISYS SV6256P 5gwifi module 150mbps 802.11a/n sdio wifi modules

Protocol：802.11a/n
Size：12*12mm
Rate：150Mbps
Frequency Band：2.4/5GHz
Interface：SDIO

Introduction

Functions

Dimension

Diagram

Pin Outline

The H256A-S module is a highly-integrated IEEE 802.11 a/b/g/n MAC/Baseband/RF WLAN single chip

The H256A-S module provides SDIO interface for Wi-Fi

The H256A-S module provides simple legacy and 20MHz/40MHz 2.4G+5G co-existence mechanisms to ensure backward and network compatibility

Application Scenario

Operate at ISM frequency bands (2.4GHz+5GHz)

CMOS MAC, Baseband PHY, and RF in a single chip for 802.11a/b/g/n compatible WLAN

Wi-Fi 1 T 1 R allow data rates supporting up to 150 Mbps PHY rates

Application Scenario
