6192A-SF
QOGRISYS RTL8192FS 2.4gwifi module 2T2R 300mbps 802.11n sdio wifi modules
Size：12.2*13mm
Rate：300Mbps
Frequency Band：2.4GHz
Interface：SDIO2.0
The 6192A-SF module is a highly integrated single-chip 802.11b/g/n 1T1R WLAN
The 6192A-SF module completes 802.11n 2x2 MIMO solution for 2.4GHz, maximum data rate up to 300Mbps using 40Mhz bandwidth
The 6192A-SF module complies with SDIO 1.1/2.0/3.0 for WLAN with clock rate up to 100Mhz
Application Scenario
12.2x13mm, 44pin, 3.3V power in
RTL8192FS
Complete 802.11n 2x2 MIMO solution for 2.4GHz, maximum data rate up to 300Mbps using 40Mhz bandwidth
Complies with SDIO 1.1/2.0/3.0 for WLAN with clock rate up to 100Mhz
Application Scenario
Application Scenario
Application Scenario
Application Scenario
