The highly integrated module makes the possibilities of web browsing, VoIP, Bluetooth headsets applications

  Support With seamless roaming capabilities and advanced security

  Support interact with different vendors’ 802.11a/b/g/n/ac 2x2 Access Points in the wireless LAN

  The wireless module complies with IEEE 802.11 a/b/g/n/ac 2x2 MIMO standard

  It can achieve up to a speed of 866Mbps with dual stream in 802.11n to connect the wireless LAN

  The integrated module provides USB2.0 interface for Wi-Fi and Bluetooth

  The module is specifically developed for Smart TV and OTT Box application

Application Scenario

  Dual-stream spatial multiplexing up to 867 Mbps data rate

  Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz

  Supports USB interface for WLAN and Bluetooth

  Complies with USB2.0 for WLAN and BT controller

  Supports Bluetooth V5.0+HS, BLE and be backwards compatible with Bluetooth 1.2, 2.X+ enhance data rate

  Supports Bluetooth for class1 , class2 and class3 power level transmissions
