L297B-SR has dual-band Wi-Fi and Bluetooth functionalities

  It is based on NXP 88W8987 chipset

  The module provides SDIO3.0 interface for Wi-Fi and HS-UART/PCM for Bluetooth

  L297B-SR can achieve up to a speed of 866Mbps with single stream 802.11ac WLAN connection

  It is a perfect solution for a combination of Wi-Fi and BT technologies

Application Scenario

  NXP 88W8987 inside

  CMOS MAC, Baseband PHY and RF in a single chip for IEEE 802.11 a/b/g/n/ac

  Maximum rate 433Mbps in 80MHz bandwidth

  SDIO3.0 interface for WLAN

  Support Bluetooth V5.0 features

  HS-UART and PCM interface for BT
