The O9001UE module is a highly integrated, high performance 802.11 b/g/n WLAN SoC chip with USB interface (USB 2.0 compliant)

  The O9001UE module integrates RF transceiver, 802.11 PHY & MAC, RISC-V CPU, OTP, USB interface and power management circuits

  The O9001UE module integrated RF circuits include power amplifier (PA), low noise amplifier (LNA), T/R switch and balun

  The O9001UE module provides a complete solution for high throughput and reliable wireless LAN application

  The O9001UE module supports all data rates for IEEE 802.11 b/g/n with one spatial stream transmission over 20MHz bandwidth

Application Scenario

  Support802.11b/g/n 1T1R WLAN

  Complies with USB2.0 for WLAN

  Maximum data rate: 54Mbps in 802.11g and 72Mbps in 802.11n

  IEEE standards support: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11e

  Support AP & STA function

  Encryption: open / WEP40 / WEP104 / TKIP / AES128 in STA mode, open / AES128 in AP mode
