After wifi embedded applications in the industry in recent years, for the large area of video and other code streams, the bandwidth requirements are relatively high, because of the IEEE 802.11ac standard, the next application for Realtek's 11ac standard wifi module Reference analysis: F11AUUM23-W1 is an RTL8811AU chip, size 23.0*17.0mm, package is LGA-9, power supply voltage DC 3V3, antenna through ANT pin extension or I-pex block external connection, 1T1R single channel maximum transmission rate up to 433.3Mbps , in line with IEEE 802.11a/b/g/n/ac standard, USB interface dual-band WiFi module; F21AUUM13-W1 is an RTL8821AU chip, size 19.0*17.1mm, package is LGA-12, power supply voltage DC 3V3, antenna through ANT pin extension or I-pex block external connection, 1T1R single channel maximum transmission rate up to 433.3Mbps ,...
-
